52 FXMP25 User Guide
www.controltechniques.com Issue Number: 3
FXMP25 Thermal Protection in Mentor 2 Mode.
The following parameter setting can be used to provide indication to the Mentor 2 if
overtemperature condition is reached.
Pr 9.23 = 1012 - digital output ST5 set to ‘drive OK / healthy’.
Pr 8.18 = 613 - digital input to control Pr 6.13 (field enable).
Pr 12.03 = 604 - use programmable threshold to detect when firing angle reaches front
end-stop.
Pr 12.04 = 1000.
Pr 9.13 = 806
Pr 9.15 = 1201 - digital output 1 indicates when firing angle end-stop is reached.
Pr 9.07 = 806
Pr 9.09 = 8.11 – drive disabled.
Pr 8.17 = 1034 – force an ‘Et’ trip if FXMP25 relay opens and firing angle reaches end-
stop and drive is disabled.
Connect digital outputs 1 and 2 and digital input 7 together.
Connect normally open contacts of FXMP25 relay to digital input 6.
