Battery Installation
21
Figure 13 Narrow battery cabinet, 27 in. (690mm) - rear view
Figure 14 Wide battery cabinet, 57 in. (1488mm) - front view
BCB plate
and BCB
Battery
trays
Top
cable
entry
Batteries
Battery tray
Top cable entry
BCB plate and
BCB
Service
shelf
Battery tray
support
