Emerson Liebert NX 10-30kVA - Table 29 Maintenance Bypass Cabinet Electrical Data (Single Input)

Specifications and Technical Data
60
Table 29 Maintenance bypass cabinet electrical data (single input)
kVA Type
Maintenance
Bypass
I/P Voltage
(VAC)
Bypass Cabinet
Max Input
Current
Cabinet
Input OCP
CB Size (A)
O/P Voltage
(VAC)
Nominal O/P
Current Rating (A)
Output
OCP CB Size (A)
30 A, J 208 104 125 208 83 125
30 B, K 480 47 60 208 83 125
30 B, K 600 37 50 208 83 125
30 B, K 220 101 125 208 83 125
30 C, L 480 48 60 480 36 50
30 C, L 600 38 50 600 29 40
30 C, L 220 105 125 220 79 100
30 D, M 480 47 60 208 83 125
30 D, M 600 38 50 208 83 125
30 D, M 208 108 150 208 83 125
30 D, M 220 103 125 208 83 125
30 D, M 240 93 125 208 83 125
30 E, N 480 48 60 480 36 50
30 E, N 600 39 50 600 29 40
30 E, N 220 106 125 220 79 100
20 A, J 208 69 90 208 56 70
20 B, K 480 31 40 208 56 70
20 B, K 600 25 30 208 56 70
20 B, K 220 68 90 208 56 70
20 C, L 480 32 40 480 24 30
20 C, L 600 26 40 600 19 30
20 C, L 220 70 90 220 52 70
20 D, M 480 31 40 208 56 70
20 D, M 600 25 40 208 56 70
20 D, M 208 72 90 208 56 70
20 D, M 220 68 90 208 56 70
20 D, M 240 62 80 208 56 70
20 E, N 480 32 40 480 24 30
20 E, N 600 26 40 600 19 30
20 E, N 220 70 90 220 52 70
15 A, J 208 52 70 208 42 60
15 B, K 480 23 30 208 42 60
15 B, K 600 19 30 208 42 60
15 B, K 220 51 70 208 42 60
15 C, L 480 24 30 480 18 30
15 C, L 600 19 30 600 14 20
15 C, L 220 52 70 220 39 50
15 D, M 480 23 30 208 42 60
15 D, M 600 19 30 208 42 60
15 D, M 208 54 70 208 42 60
15 D, M 220 51 70 208 42 60
