UPS Specifications
39
6.4 UPS Electrical Characteristics
Table 10 UPS terminal
Input (for single-input unit)
Unit
Rating
Nominal
Input
Current
Maximum
Input
Current
OCP
Current
OCP
Device
Rating Bolt Size
Maximum Recommended Lug
Lug T&B
One Hole 54000
Lug T&B
One Hole REDDY
10 28 35 42 45 6M (1/4”) 54105 62204
15 42 53 63 70 6M (1/4”) 54106 62204
20 56 70 84 90 6M (1/4”) 54107 62204
30 83 104 125 125 6M (1/4”) 54152 62205
Rectifier input (for dual input unit only)
Unit
Rating
Nominal
Input
Current
Maximum
Input
Current
OCP
Current
OCP
Device
Rating Bolt Size
Maximum Recommended Lug
Lug T&B
One Hole 54000
Lug T&B
One Hole REDDY
10 25 31 37 40 6M (1/4”) 54130 62204
15 37 47 57 60 6M (1/4”) 54106 62204
20 50 63 76 80 6M (1/4”) 54107 62204
30 75 94 113 125 6M (1/4”) 54152 62205
Bypass input (for dual input units)
Unit
Rating
Nominal
Input
Current
OCP
Current
OCP
Device
Rating Bolt Size
Maximum Recommended Lug
Lug T&B
One Hole
54000
Lug T&B
One Hole
REDDY
10 28 35 35 6M (1/4”) 54105 62204
15 42 53 60 6M (1/4”) 54106 62204
20 56 70 70 6M (1/4”) 54107 62204
30 83 104 110 6M (1/4”) 54152 62205
Output
Unit
Rating
Nominal
Output
Current
OCP
Current
OCP
Device
Rating Bolt Size
Maximum Recommended Lug
Lug T&B
One Hole 54000
Lug T&B
One Hole REDDY
10 28 35 35 6M (1/4”) 54130 62204
15 42 53 60 6M (1/4”) 54106 62204
20 56 70 70 6M (1/4”) 54106 62204
30 84 105 110 6M (1/4”) 54108 62205
Battery
Unit
Rating
Battery
Current
OCP
Current
OCP
Device
Rating Bolt Size
Maximum Recommended Lug
Lug T&B
One Hole 54000
Lug T&B
One Hole REDDY
10/15 55 55 70 6M (1/4”) 54106 62204
20/30 110 110 125 8M (5/16”) 54153 62212
