Emerson Liebert OpenComms-485 - Page 37

REV. 5 7/6/2007
Liebert Monitoring Group –Development
34
Events/Alarm
EventCount
Summary Alarm
Status [8]
30102 - - -
EnvState.
AlarmState
Fan Ramp 30103 - 1 %
EnvState.
FanRamp
Cooling Ramp 30104 - 1 %
EnvState.
CoolRamp
Free Cooling
Ramp
30105 - 1 %
EnvState.
FCRamp
Heating Ramp 30106 - 1 %
EnvState.
HeatRamp
Humidification
Ramp
30107 - 1 %
EnvState.
HumRamp
Dehumidifier
Ramp
30108 - 1 %
EnvState.
DehumRamp
FreeCooling
Status [9]
30109 - 1 % U312
Return
Temperature
30110 - x10 C°
EnvState.
ActTemp
Actual
Temperature SP
30111 - x10 C° U301(ActTemp
Set)
Supply
Temperature
30112 - x10 C°
EnvState.ActSup
Actual Supply
Temperature SP
30113 - x10 C°
EnvState.
ActSupSet
FC Temperature 30115 - x10 C° U309
Sensor A
Temperature
30116 - x10 C° U303
Sensor B
Temperature
30117 - x10 C° U305
Sensor C
Temperature
30118 - x10 C° U307
Digi Scroll 1
Temperature
30119 - x10 C° U310
Digi Scroll 2
Temperature
30120 - x10 C° U311
Return Humidity 30130 - 1 %
EnvState.ActTe
mp
Actual Humidity
SP
30131 - 1 % U302(ActHumS
et)
Sensor A
Humidity
30132 - 1 % U304
Sensor B
Humidity
30133 - 1 % U306
Sensor C
Humidity
30134 - 1 % U308
Fan Run Hour 30141 - 1 Hour S502
Compressor 1
Run Hour
30142 - 1 Hour S503
Compressor 2
Run Hour
30143 - 1 Hour S504
Humidifier run
hours
30144 - 1 Hour S510
Dehumidification
run hours
30145 - 1 Hour S511
