Figure 3-9 Size 2C front view and mounting dimensions
6mm (0.24in)
175mm (6.9in)
5mm
(0.2in)
175mm (6.9in)
405mm (15.94)
248mm (9.76in)
202mm (7.95in)
321mm (12.64in)
605mm (23.82in)
124mm
(4.89in)
175mm (6.9in)
555mm (21.85in)
452mm (17.8in)
2
0
2
m
m
(
7
.
9
5
i
n
)
390mm (15.35in)
