76 Chapter 5 Use Of Monitoring Module M800D
Table 1.1 Contents of M800D MIB
Ident group M800D ident group R/W
*
identManufacturer The name of the equipment manufacturer R
identModel The manufacturers model designation of the power system R
identControllerFirmwareVersion The firmware (software) version of the controller R
identName The name of the power plant. This object should be set by the administrator R/W
System Group M800D system value group
systemStatus
Status of the complete plant (highest alarm). One of
(1) unknown – status has not yet been defined
(2) normal – there are no activated alarms
(3) warning – OA, lowest level of ‘abnormal’ status
(4) minor – A3
(5) major – MA
(6) critical – CA, highest level of ‘abnormal’ status
(7) unmanaged
(8) restricted
(9) testing
(10) disabled
R
systemVoltage System voltage, stored as mV R
systemCurrent System current, stored as Ma R
systemUsedCapacity Used capacity, stored as % of the total capacity R
psStatusCommunication
The status of communication with the Power System
(1) unknown,
(2) normal,
(3) interrupt indicates some errors occurred between Power System and agent
psStatusBatteryMode
The status of battery modes,
(1) unknown
(2) FloatCharging,
(3) ShortTest,
(4) BoostChargingForTest
(5) ManualTesting, (6) PlanTesting, (7) ACFailTesting, (8) ACFail,
(9) ManualBoostCharging, (10)AutoBoostCharging,
(11)CyclicBoostCharging, (12)MasterBoostCharging,
(13)MasterBatteryTesting
SM series group Power system battery group
psSMACNumber The number of SM AC module R
psSMBATNumber The number of SM BAT module R
psSMIONumber The number of SM IO module R
psInput group Power system input group
psInputLineAVoltage The AC line A voltage, stored as mV R
psInputLineBVoltage The AC line B voltage, stored as mV R
psInputLineCVoltage The AC line C voltage, stored as mV R
psTemperature Group Power system temperature group
psTemperature1 The first route temperature, stored as 0.001 Celsius degree R
psTemperature2 The second route temperature, stored as 0.001 Celsius degree R
alarm trap Group M800D alarm trap Group
alarmLastTrapNo The sequence number of last submitted alarm trap R
alarmTrapTable
(alarmTrapEntry)
Table holding information about the submitted alarm traps. AlarmTrapEntry is the
entry (conceptual row) in the alarmTrapTable
R
alarmTrapNo The unique sequence number of this alarm trap R
alarmTime
Date and time when event occured (local time), including timezone if supported by
controller
R
alarmStatusChange
The type of alarm change. One of
(1) activated
(2) deactivated
R
alarmSeverity
The severity of the alarm. One of
(3) warning – O1, lowest level of alarm severity
(4) minor – A3
(5) major – A2
(6) critical – A1, highest level of alarm severity
R
alarmDescription Free-text description of alarm R
alarmType Alarm type, i.e. an integer specifying the type of alarm
Traps Alarm traps info
The SNMP agent can send the active alarms to the specified NMSs and the user
can define the lowest severity of the NMS accepted alarms
