Emerson PeC C100 User Manual

AGL_Sol_PEC_01_E_Rev01 7
Input no.
Type of input
Description
22
V2 valve
Bipolar valve output
23
V3 valve
Bipolar valve output
24
V1 valve
Bipolar valve output
25
PE
Connector to PE for EMC
30
V+
▪ Power supply pressure transducer +24 VDC (output)
▪ Future use: 5 VDC supply for ratiometric pressure transducer
31
PB1
▪ Analog input (4-20 mA)
▪ Future use: 0-5 VDC signal input for ratiometric pressure transducer
32
GND
▪ GND reference for ratiometric pressure transducer for future use
33
V+
▪ Power supply pressure transducer +24 VDC (output)
▪ Future use: 5 VDC supply for ratiometric pressure transducer
34
PB2
▪ Analog input (4-20 mA)
▪ Future use: 0-5 VDC signal input for ratiometric pressure transducer
35
GND
GND reference for ratiometric pressure transducer
36
GND
Analog input GND
37
GND
Analog input GND
38
GND
Analog input GND
39
GND
Analog input GND
40
GND
Analog input GND
41
PB3
Analog input 3 (TP1-NPx)
42
PB4
Analog input 4 (TP1-NPx)
43
PB5
Analog input 5 (TP1-NPx)
44
PB6
Analog input 6 (TP1-NPx)
45
PB7
Analog input 7 (TP1-NPx)
46
PB8
Analog input 8 (TP1-NPx)
47
PB9
Analog input 9 ((TP1-NPx)
48
10 V.
Analog input (0-10 Volt)
49
GND
GND reference (0-10 Volt)
50
RS485 +
RS485 Master connection (+)
51
RS485 -
RS485 Master connection (-)
52
GND
Ground reference for RS485
53
RS485 +
RS485 Slave connection (+)
54
RS485 -
RS485 Slave connection (-)
55
GND
Ground reference for RS485
56
RS485 +
RS485 Slave connection (+)
57
RS485 -
RS485 Slave connection (-)
58
GND
Ground reference for RS485
Table 3
2.3.1.3 Analog inputs
Analog conversion type
12-bit A/D converter
Number of inputs
9
Type of analog input
(configurable via software parameter)
NTC Emerson (10 KΩ ± 1 % at 25 °C) -40 °C to 150 °C.
NTC Emerson (100 KΩ ± 1 % at 25 °C) 0 °C to 170 °C
(future use)
Voltage: 0-10 V (input resistance 9 KΩ)
Current: 4-20 mA (input resistance 100 Ω)
Digital input status variation detection time
100 ms
Accuracy
See graph below (Figure 2) for more details
Table 4
