Emerson PeC C100 User Manual

12 AGL_Sol_PEC_01_E_Rev01
Input no.
Type of input
Description
12
RL4-C
Common relay 4 (230 VAC, max, 5 A resistive, 2 A inductive cos φ 0.5
switching capability)
13
DI1 C
Opto-insulated digital input 1 1(24-230 VAC/DC)
14
Com
Common opto-insulated digital input 1
15
DI2 C
Potential free digital input 2
16
Com
Potential free digital input 2
17
DI3 C
Potential free digital input 3
18
Com
Potential free digital input 3
21
V4 valve
Bipolar valve output (circuit 1)
22
V2 valve
Bipolar valve output (circuit 1)
23
V3 valve
Bipolar valve output (circuit 1)
24
V1 valve
Bipolar valve output (circuit 1)
25
PE
Connector to PE for EMC
30
V+
▪ Power supply pressure transducer +24 VDC (output)
▪ Future use: 5 VDC supply for ratiometric pressure transducer
31
PB1
▪ Analog input (4-20 mA)
▪ Future use: 0-5 VDC signal input for ratiometric pressure transducer
32
GND
GND reference for ratiometric pressure transducer for future use
33
V+
▪ Power supply pressure transducer +24 VDC (output)
▪ Future use: 5 VDC supply for ratiometric pressure transducer
34
PB2
▪ Analog input (4-20 mA)
▪ Future use: 0-5 VDC signal input for ratiometric pressure transducer
35
GND
GND reference for ratiometric pressure transducer for future use
36
GND
Analog input GND
37
GND
Analog input GND
38
GND
Analog input GND
39
GND
Analog input GND
40
GND
Analog input GND
41
PB3
Analog input 3 (TP1-NPx)
42
PB4
Analog input 4 (TP1-NPx)
43
PB5
Analog input 5 (TP1-NPx)
44
PB6
Analog input 6 (TP1-NPx)
45
PB7
Analog input 7 (TP1-NPx)
46
PB8
Analog input 8 (TP1-NPx)
47
PB9
Analog input 9 (TP1-NPx)
48
10 V
Analog input (0-10 Volt)
49
GND
GND reference (0-10 Volt)
50
RS485 +
RS485 Master connection (+)
51
RS485 -
RS485 Master connection (-)
52
GND
Ground reference for RS485
53
RS485 +
RS485 Slave connection (+)
54
RS485 -
RS485 Slave connection (-)
55
GND
Ground reference for RS485
56
RS485 +
RS485 Slave connection (+)
57
RS485 -
RS485 Slave connection (-)
58
GND
Ground reference for RS485
60
DI4 C
Opto-insulated digital input 4 (24-230 VAC/DC)
61
Com
Common opto-insulated digital input 1
62
RL5-NO
Relay 5 NO contact
