Emerson PeC C100 User Manual

AGL_Sol_PEC_01_E_Rev01 13
Input no.
Type of input
Description
63
RL5-C
Common relay 5 (230 VAC, max, 5 A resistive, 2 A inductive cos φ 0.5
switching capability)
64
RL6-NO
Relay 6 NO contact
65
RL6-C
Common relay 6 (230 VAC, max, 5 A resistive, 2 A inductive cos φ 0.5
switching capability)
66
RL7-NO
Relay 7 NO contact
67
RL7-C
Common relay 7 (230 VAC, max, 5 A resistive, 2 A inductive cos φ 0.5
switching capability)
68
RL8-NO
Relay 8 NO contact
69
RL8-C
Common relay 8 (230 VAC, max, 5 A resistive, 2 A inductive cos φ 0.5
switching capability)
70
V4 valve
Bipolar valve output (circuit 2)
71
V2 valve
Bipolar valve output (circuit 2)
72
V3 valve
Bipolar valve output (circuit 2)
73
V1 valve
Bipolar valve output (circuit 2)
80
V+
▪ Power supply pressure transducer +24 VDC (output)
▪ Future use: 5 VDC supply for ratiometric pressure transducer
81
PB10
▪ Analog input (4-20 mA)
▪ Future use: 0-5 VDC signal input for ratiometric pressure transducer
82
GND
GND reference for ratiometric pressure transducer for future use
83
V+
▪ Power supply pressure transducer +24 VDC (output)
▪ Future use: 5 VDC supply for ratiometric pressure transducer
84
PB11
▪ Analog input (4-20 mA)
▪ Future use: 0-5 VDC signal input for ratiometric pressure transducer
85
GND
GND reference for 5VDC/24VDC and analog inputs
86
GND
Analog input GND
87
GND
Analog input GND
88
GND
Analog input GND
89
GND
Analog input GND
90
PB12
Analog input 12 (TP1-NPx)
91
PB13
Analog input 13 (TP1-NPx)
92
PB14
Analog input 14 (TP1-NPx)
93
PB15
Analog input 15 (TP1-NPx)
94
PB16
Analog input 16 (TP1-NPx)
95
PB17
Analog input 17 (TP1-NPx)
Table 10
2.3.2.3 Analog inputs
Analog conversion type
12-bit A/D converter
Number of inputs
9
Type of analog input
(configurable via software parameter)
NTC Emerson (10 KΩ ± 1 % at 25 °C) -40 °C to 150 °C.
NTC Emerson (100 KΩ ± 1 % at 25 °C) 0 °C to 170 °C
(future use)
Voltage: 0-10 V (input resistance 9 KΩ)
Current: 4-20 mA (input resistance 100 Ω)
Digital input status variation detection time
100 ms
Accuracy
See graph below (Figure 6) for more details
Additional power
+24 V: max 25 mA per channel
+5 V: (future use)
Table 11
