Product Certifications
SAFETY NOTE
A safety isolator such as a zener barrier is always needed for
intrinsic safety.
Probes covered with plastic and/or with plastic discs may generate
an ignition-capable level of electrostatic charge under certain
extreme conditions. Therefore, when the probe is used in a
potentially explosive atmosphere, appropriate measures must be
taken to prevent electrostatic discharge.
Factory Mutual (FM) Approval
Project ID: 3020497
E5 Explosion-proof for Class I, Div. 1,
Groups B, C, and D;
Dust Ignition Proof for Class II/III, Div. 1, Groups E, F, and G;
With Intrinsically Safe connections to
Class I, II, III, Div. 1, Groups B, C, D, E, F, and G.
Temp. Code T4
Ambient temperature limits: -50 °C to +70 °C
(3)
.
Seal not required.
Approval valid for HART, F
OUNDATION fieldbus, and Modbus
options.
I5, IE Intrinsically Safe for Class I, II, III, Div. 1, Groups A, B, C, D,
E, F, and G,
Class I, Zone 0, AEx ia IIC T4 when installed per Control
Drawing: 9240 030-936.
Non-Incendive Class I, II, Div. 2, Groups A, B, C, D, F, and G;
Suitable for Class III, Div. 2.
4-20 mA / HART model: U
i
=30 Vdc, I
i
=130 mA, P
i
=1.0 W,
C
i
=7.26 nF, L
i
=0 H.
F
OUNDATION fieldbus model: U
i
=30 Vdc, I
i
=300 mA,
P
i
=1.3 W, C
i
=0 nF, L
i
=0 H.
FISCO model: U
i
=17.5 Vdc, I
i
=380 mA, P
i
=5.32 W, L
i
=C
i
=0.
Temp. Code T4
Ambient temperature limits: -50 °C to +70 °C
(3)
Approval valid for HART, FOUNDATION fieldbus, and FISCO
options.
EU Conformity
The most recent revision of the EC declaration of conformity
can be found at www.rosemount.com
.
Safety Instrumented Systems (SIS)
The Rosemount 5300 Series has been evaluated by a third
party, Exida, against hardware requirements according to
IEC 61508. With a FMEDA (Failure Modes, Effects and
Diagnostics Analysis) report with a Safe Failure Fraction
(SFF) above 90%, 5300 is suitable in SIS according to the
Prior Use methodology. For more information, go to:
http://www.emersonprocess.com/rosemount/safety/. To
order the certificate of FMEDA data use option code QS.
ATEX Approval
Nemko 04ATEX1073X
SPECIAL CONDITIONS FOR SAFE USE (X)
The intrinsically safe circuits do not withstand the 500 Vac test as
specified in IEC 60079-11 clause 6.4.12.
Impact and friction hazards need to be considered according to
EN 60079-0 clause 8.1.2 when the transmitter and part of
antennas exposed to the exterior atmosphere of the tank is made
with light metal alloys and of category II 1G EPL Ga.
The Ex ia version of model 5300 FISCO field device may be
supplied by an [Ex ib] FISCO power supply when the power supply
is certified with three separate safety current limiting devices and
voltage limitation which meets the requirements for type Ex ia.
E1
(1)
Flameproof:
II 1/2 G T4
II 1D T79°C
(2)
.
Ex ia/db ia IIC T4 Ga/Gb (-40 °CT
a
+70 °C
(3)
)
Ex ta IIIC T79°C
(2)
(-40 °CT
a
+70 °C
(3)
)
U
m = 250 V.
Approval valid for HART, F
OUNDATION fieldbus, and Modbus
options.
I1
(1)
, IA
(1)
Intrinsically Safe:
II 1 G T4.
II 1/2 G T4
II 1 D T79°C
(2)
Ex ia IIC T4 (-50 °CT
a
+70 °C
(3)
).
Ex ia/ib IIC T4 Ga/Gb (-50 °CT
a
+70 °C
(3)
).
Ex ta IIIC T79°C
(2)
(-50 °CT
a
+70 °C
(3)
).
4-20 mA / HART model: U
i
=30 Vdc, I
i
=130 mA, P
i
=1.0 W,
C
i
=7.26 nF, L
i
=0 H.
F
OUNDATION fieldbus model: U
i
=30 Vdc, I
i
=300 mA,
P
i
=1.5 W, C
i
=0 nF, L
i
=0 H.
FISCO model: U
i
=17.5 Vdc, I
i
=380 mA, P
i
=5.32 W, C
i
=0 nF,
L
i
<1 μH.
Installation Drawing: 9240 030-938
Approval valid for HART, F
OUNDATION fieldbus, and FISCO
options.
(1) Ordering Information Code for Product Certificates, see page 8 and page 13.
(2) +69 °C with F
OUNDATION fieldbus or FISCO option.
(3) +60 °C with F
OUNDATION fieldbus or FISCO option.
