Product Data Sheet
00813-0100-4530, Rev DA
December 2010
9
Rosemount 5300 Series
LS Long stud
(24)
9.8 in (250 mm) for flexible single lead probe to prevent contact with wall/nozzle.
Standard height is 3.9 in (100 mm) for probes 5A and 5B.
★
T1 Transient Protection Terminal Block (standard with FISCO options) ★
W3 2.2 lb (1 kg) weight for flexible single lead probe (5A). L=5.5 in. (140 mm) ★
Expanded
BR Mounting Bracket for 1.5 in. NPT Process Connection (RA)
W2 0.79 lb (0.36 kg) short weight for flexible single lead probe
(25)
. L=2 in. (50 mm)
Special Configuration (Software)
Standard Standard
C1 Factory configuration (CDS required with order) ★
C4 Namur alarm and saturation levels, high alarm ★
C5 Namur alarm and saturation levels, low alarm ★
C8 Low alarm
(26)
(standard Rosemount alarm and saturation levels) ★
Special Certifications
Standard Standard
Q4 Calibration Data Certification ★
Q8 Material Traceability Certification per EN 10204 3.1
(27)
★
QS Prior-use certificate of FMEDA Data. Only available with HART 4-20 mA output (output code H). ★
U1 WHG Overfill Approval. Only available with HART 4-20 mA output (output code H) ★
Expanded
QG GOST Primary Verification Certificate
PlantWeb Diagnostic Functionality
Standard Standard
D01 F
OUNDATION fieldbus Diagnostics Suite ★
DA1 HART Diagnostics Suite ★
Centering Discs Outer Diameter
Standard Standard
S2 2 in. Centering disc
(28)
1.8 in. (45 mm) ★
S3 3 in. Centering disc
(28)
2.7 in. (68 mm) ★
S4 4 in. Centering disc
(28)
3.6 in. (92 mm) ★
P2 2 in. Centering disc PTFE
(29)
1.8 in. (45 mm) ★
P3 3 in. Centering disc PTFE
(29)
2.7 in. (68 mm) ★
P4 4 in. Centering disc PTFE
(29)
3.6 in. (92 mm) ★
Expanded
S6 6 in. Centering disc
(28)
5.55 in. (141 mm)
S8 8 in. Centering disc
(28)
7.40 in. (188 mm)
P6 6 in. Centering disc PTFE
(29)
5.55 in. (141 mm)
P8 8 in. Centering disc PTFE
(29)
7.40 in. (188 mm)
Remote Housing Mounting
Expanded
B1 1m / 3.2 ft. Remote Housing Mounting Cable and Bracket
B2 2m / 6.5 ft. Remote Housing Mounting Cable and Bracket
B3 3m / 9.8 ft. Remote Housing Mounting Cable and Bracket
Consolidate to Chamber
Expanded
XC Consolidate to Chamber
(30)
(1) Not available with Flame/Explosion-proof approvals (E1, E3, E5, E6, E7, KA, KB, KC, and KD)
(2) Process seal rating. Final rating depends on flange and O-ring selection. See “Temperature and Pressure Limits” on page 22.
TABLE 1. 5301 and 5302 Level and/or Interface in Liquids Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
The Expanded offering is subject to additional delivery lead time.
