Emerson Rosemount 8800D Series Safety Manual

2 Installation and commissioning
Topics covered in this chapter:
•
Identification of SIS certified transmitter
•
Set up the flowmeter
•
Enable transmitter write protection
•
Set failure mode
•
Flow simulation diagnostic
•
Replace equipment
Use this chapter to install and commission the Rosemount 8800D Series SIL 2/3 Capable
Vortex Flowmeter.
2.1 Identification of SIS certified transmitter
IEC 61508 relevant requirements
The Rosemount 8800D is certified per the relevant requirements of IEC 61508.
Systematic capability
Safety Integrity Level (SIL) 3 capable
Random capability • Type B element
• SIL 2 capable @ HFT=0 (single transmitter)
• SIL 3 capable @ HFT=1 (dual transmitters)
• SIL 3 capable @ HFT=2 (quadruple transmitters)
Failure rates per IEC 61508 in FIT
Rosemount 8800D Series SIL 2/3 Capable Vortex FlowmeterTable 2-1:
Failure categories λ
SD
λ
SU
λ
DD
λ
DU
Low Flow Trip 0 76 387 74
High Flow Trip 0 32 387 119
SIS-certified versions
All Rosemount 8800D Vortex Flowmeters must be identified as safety certified before
installing into SIS systems. To identify a safety certified Rosemount 8800D Vortex
Flowmeter, requirements 1 and 2, or requirements 2 and 3 must be satisfied. The
requirements are:
Installation and commissioning
Safety Manual 7
