Emerson Process Management GmbH & Co. OHG 9-11
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
9
Modbus Commands
9.3 List of Parameters and Registers - Sorted by Tag Name
Tag Name Address
Data
Type
Client
Access
Description
Modicon Daniel
Service.Measurement.Lin.MaxValue2
7383…
7384
9692 Float RO Linearizer Maximum Value of comp2
Service.Measurement.Lin.MaxValue3
7583…
7584
9792 Float RO Linearizer Maximum Value of comp3
Service.Measurement.Lin.MaxValue4
7783…
7784
9892 Float RO Linearizer Maximum Value of comp4
Service.Measurement.Lin.MaxValue5
7983…
7984
9992 Float RO Linearizer Maximum Value of comp5
Service.Measurement.Lin.Method1 3506 3506 Word R/W
Linearization method of comp1
(0=Splines, 1=Polynom)
Service.Measurement.Lin.Method2 3507 3507 Word R/W
Linearization method of comp2
(0=Splines, 1=Polynom)
Service.Measurement.Lin.Method3 3508 3508 Word R/W
Linearization method of comp3
(0=Splines, 1=Polynom)
Service.Measurement.Lin.Method4 3509 3509 Word R/W
Linearization method of comp4
(0=Splines, 1=Polynom)
Service.Measurement.Lin.Method5 3510 3510 Word R/W
Linearization method of comp5
(0=Splines, 1=Polynom)
Service.Measurement.Lin.MinValue1
7181…
7182
9591 Float RO Linearizer Minimum Value of comp1
Service.Measurement.Lin.MinValue2
7381…
7382
9691 Float RO Linearizer Minimum Value of comp2
Service.Measurement.Lin.MinValue3
7581…
7582
9791 Float RO Linearizer Minimum Value of comp3
Service.Measurement.Lin.MinValue4
7781…
7782
9891 Float RO Linearizer Minimum Value of comp4
Service.Measurement.Lin.MinValue5
7981…
7982
9991 Float RO Linearizer Minimum Value of comp5
Service.Measurement.Lin.OverowPerc1
7161…
7168
9581…
9584
Float R/W
Lin-Overow [%] for Range1..4 of
comp1
Service.Measurement.Lin.OverowPerc2
7361…
7368
9681…
9684
Float R/W
Lin-Overow [%] for Range1..4 of
comp2
Service.Measurement.Lin.OverowPerc3
7561…
7568
9781…
9784
Float R/W
Lin-Overow [%] for Range1..4 of
comp3
Service.Measurement.Lin.OverowPerc4
7761…
7768
9881…
9884
Float R/W
Lin-Overow [%] for Range1..4 of
comp4
Service.Measurement.Lin.OverowPerc5
7961…
7968
9981…
9984
Float R/W
Lin-Overow [%] for Range1..4 of
comp5
Service.Measurement.Lin.RangePolySet1
3531…
3534
3531…
3534
Word R/W
polyn. set of range1..4 comp1 (0=Poly1
1=Poly2 2=Poly3 3=Poly4)
Service.Measurement.Lin.RangePolySet2
3535…
3538
3535…
3538
Word R/W
polyn. set of range1..4 comp2 (0=Poly1
1=Poly2 2=Poly3 3=Poly4)
Service.Measurement.Lin.RangePolySet3
3539…
3542
3539…
3542
Word R/W
polyn. set of range1..4 comp3 (0=Poly1
1=Poly2 2=Poly3 3=Poly4)
Service.Measurement.Lin.RangePolySet4
3543…
3546
3543…
3546
Word R/W
polyn. set of range1..4 comp4 (0=Poly1
1=Poly2 2=Poly3 3=Poly4)
