9.3 List of Parameters and Registers - Sorted by Tag Name
Tag Name Address
Data
Type
Client
Access
Description
Modicon Daniel
Service.Measurement.Lin.CalcSets4 3529 3529 Word R/W
LinFct PolySets (0=All 1=P1 2=P2
3=P3 4=P4) comp4
Service.Measurement.Lin.CalcSets5 3530 3530 Word R/W
LinFct PolySets (0=All 1=P1 2=P2
3=P3 4=P4) comp5
Service.Measurement.Lin.CutOff1
7185…
7186
9593 Float R/W Linearizer Cut-off value of comp1
Service.Measurement.Lin.CutOff2
7385…
7386
9693 Float R/W Linearizer Cut-off value of comp1
Service.Measurement.Lin.CutOff3
7585…
7586
9793 Float R/W Linearizer Cut-off value of comp1
Service.Measurement.Lin.CutOff4
7785…
7786
9893 Float R/W Linearizer Cut-off value of comp1
Service.Measurement.Lin.CutOff5
7985…
7986
9993 Float R/W Linearizer Cut-off value of comp1
Service.Measurement.Lin.Enable1 3501 3501 Word R/W Enable Linearizer of comp1
Service.Measurement.Lin.Enable2 3502 3502 Word R/W Enable Linearizer of comp1
Service.Measurement.Lin.Enable3 3503 3503 Word R/W Enable Linearizer of comp1
Service.Measurement.Lin.Enable4 3504 3504 Word R/W Enable Linearizer of comp1
Service.Measurement.Lin.Enable5 3505 3505 Word R/W Enable Linearizer of comp1
Service.Measurement.Lin.EnablePolyn1
3551…
3554
3551…
3554
Word R/W
Enable polyn. linearizers (R1..R4) of
comp1
Service.Measurement.Lin.EnablePolyn2
3555…
3558
3555…
3558
Word R/W
Enable polyn. linearizers (R1..R4) of
comp2
Service.Measurement.Lin.EnablePolyn3
3559…
3562
3559…
3562
Word R/W
Enable polyn. linearizers (R1..R4) of
comp3
Service.Measurement.Lin.EnablePolyn4
3563…
3566
3563…
3566
Word R/W
Enable polyn. linearizers (R1..R4) of
comp4
Service.Measurement.Lin.EnablePolyn5
3567…
3570
3567…
3570
Word R/W
Enable polyn. linearizers (R1..R4) of
comp5
Service.Measurement.Lin.Iterations1
3521 3521 Word R/W Lin-computing iteration steps of comp1)
Service.Measurement.Lin.Iterations2 3522 3522 Word R/W Lin-computing iteration steps of comp1)
Service.Measurement.Lin.Iterations3 3523 3523 Word R/W Lin-computing iteration steps of comp1)
Service.Measurement.Lin.Iterations4 3524 3524 Word R/W Lin-computing iteration steps of comp1)
Service.Measurement.Lin.Iterations5 3525 3525 Word R/W Lin-computing iteration steps of comp1)
Service.Measurement.Lin.LinearizerStatus1 3516 3516 Word RO
Lin. status comp1 (0=Normal 1=Under-
ow 2=Overow 3=Undened)
Service.Measurement.Lin.LinearizerStatus2 3517 3517 Word RO
Lin. status comp2 (0=Normal 1=Under-
ow 2=Overow 3=Undened)
Service.Measurement.Lin.LinearizerStatus3 3518 3518 Word RO
Lin. status comp3 (0=Normal 1=Under-
ow 2=Overow 3=Undened)
Service.Measurement.Lin.LinearizerStatus4 3519 3519 Word RO
Lin. status comp4 (0=Normal 1=Under-
ow 2=Overow 3=Undened)
Service.Measurement.Lin.LinearizerStatus5 3520 3520 Word RO
Lin. status comp5 (0=Normal 1=Under-
ow 2=Overow 3=Undened)
Service.Measurement.Lin.MaxValue1
7183…
7184
9592 Float RO Linearizer Maximum Value of comp1
