Europe, Middle East, and Africa Only
Actuator Pilot
Item Description
1 Plate
2 Releasing bushing
3 Screw
4* Gasket
5 Balls holder
6 Stem
7 Roller
8* O-ring
9 Reloading nut
10 Ball - Roller
11 Roller
12 Screw
13 Reloading bushing
14* O-ring
15 Ring
17 Reloading lever unit
18 Self-locking nut
19 Washer
20 Return lever
21 Spring
22 Fulcrum
24 Label
26 Nut
27 Screw
28 Reloading pin
29 Screw
30 Self-locking nut
Item Description
31 Washer
32 Plate fulcrum
33 Lever
34 Screw
35 Cone
36 Releasing lever
37 Spring
38 Plug
39 Locking pin
40 Screw
41 Indicator pin
42 On-Off indicator
43 Button
44* O-ring
45 Spring
46 Gasket
47 Casing
48 Screw
49 Minimum pressure adjusting screw
50 Maximum pressure adjusting nut
51 Pipe assembly
52 Washer
53 Spring
54 Spring
55 Lower spring holder unit
56 Seeger ring
57 Stem unit
58 Spring
59 Plate holding stem unit
60 Top cover
61 Lower cover
62* Diaphragm
63 Screw
64 Block
65* O-ring
66* Gaco ex
67* O-ring
68 Piston
69 Nut
70 Locknut
71 Microswitch
73* Gasket (only for BP, BPA-D, MPA-D)
74 Filter
Item Description
1 Adjusting screw
2 Nut
3 Cap
4* O-ring
5* O-ring
6 Spring carrier plate
7 Spring
8 Upper cover
9 Spring carrier plate
10 Screw
11 Washer
Item Description
100 Inlet ange
107* O-ring
110 Disk
111 Washer
112 Nut
113 Stud bolt
114 Spring
115* O-ring
117 Sleeve
119 Anti-friction ring
120* O-ring
121 Shaft unit
122 Seeger ring
123 Pin
124 Hub
125* O-ring
126* O-ring
127 Disk
128 Bearing
133 Special screw
135 Screw
137 Lever unit
190 Stub pipe
191 Fitting
192 Hub
193 Shaft
