16 Unidrive M300/HS30 Quick Start Guide
Issue Number: 6
Figure 4-1 Pr 00.005 = AV (50 and 60 Hz)
Figure 4-2 Pr 00.005 = AI (50 and 60 Hz)
1
2
4
0V
Current speed reference
input (AI 1)
Voltage speed
reference input (AI 2)
5
7
Analog output 1
(motor frequency)
+ 10 V output
9
10
11
Digital output
(zero frequency)
Unassigned
12
13
14
Run reverse
Run forward
Analog input 1/
input 2 select
+ 24 V output
10k
Current speed
reference input
Unidrive M300 Quick Start Guide English Iss6.book Page 16 Tuesday, September 22, 2015 3:21 PM
