4.14 Transferring data
Data transfer, erasing and protecting the information is performed by entering a code in Pr mm.000
and then resetting the drive as shown in Table 4-4.
Table 4-4 SMARTCARD and SD card codes
Code Operation SMARTCARD SD card
2001
Transfer the drive parameters to parameter file 001 and
sets the block as bootable. This will include the parameters
from attached option modules.
99
4yyy
Transfer the drive parameters to parameter file yyy. This
will include the parameters from attached option modules.
99
5yyy
Transfer the onboard user program to onboard user
program file yyy.
99
6yyy
Load the drive parameters from parameter file yyy or the
onboard user program from onboard user program file yyy.
99
7yyy Erase file yyy. 99
8yyy
Compare the data in the drive with file yyy. If the files are
the same then Pr mm.000 (mm.000) is simply reset to 0
when the compare is complete. If the files are different a
‘Card Compare’ trip is initiated. All other NV media card
trips also apply.
99
9555 Clear the warning suppression flag 99
9666 Set the warning suppression flag 99
9777 Clear the read-only flag 99
9888 Set the read-only flag 99
9999 Erase and format the NV media card 99
15yyy
Transfer a program from an option module in slot 1 to an
option module applications file
9
16yyy As 15yyy, but for slot 2 9
17yyy As 15yyy, but for slot 3 9
18yyy
Load a program to the option module in slot 1 from an
option module applications file
9
19yyy As 18yyy, but for slot 2
9
20yyy As 18yyy, but for slot 3
9
21yyy As 15yyy, but for slot 4
9
22yyy As 18yyy, but for slot 4 9
40yyy
Backup all drive data (parameter differences from defaults,
an onboard user program, applications programs and
miscellaneous option data), including the drive name; the
store will occur to the </MCDF/driveyyy/> folder; if it does
not exist, it will be created. Because the name is stored, this
is a backup, rather than a clone. The command code will be
cleared when all drive and option data have been saved.
9
60yyy
Load all drive data (parameter differences from defaults, an
onboard user program, applications programs and
miscellaneous option data); the load will come from the
</MCDF/driveyyy/> folder. The command code will not be
cleared until the drive and all option data have been
loaded.
9
