28 Unidrive M702 / HS72 Control Getting Started Guide
Issue Number: 2
Table 5-2 Functions in Pr mm.000
* See section 4.13 NV Media Card operation on page 21 for more information on these functions.
** These functions do not require a drive reset to become active. All other functions require a drive
reset to initiate the function.
Value Action
1000
Save parameters when Under Voltage Active (Pr 10.016) is not active and Low Under Voltage
Threshold Select mode (Pr 06.067 = Off) is not active.
1001 Save parameter under all conditions
1070 Reset all option modules
1233 Load standard (50 Hz) defaults
1234 Load standard (50 Hz) defaults to all menus except option module menus (i.e 15 to 20 and 24 to 28)
1244 Load US (60 Hz) defaults
1245 Load US (60 Hz) defaults to all menus except option module menus (i.e 15 to 20 and 24 to 28)
1253 Change drive mode and load standard (50 Hz) defaults
1254 Change drive mode and load US (60 Hz) defaults
1255 Change drive mode and load standard (50 Hz) defaults except for menus 15 to 20 and 24 to 28
1256 Change drive mode and load US (60 Hz) defaults except for menus 15 to 20 and 24 to 28
1299 Reset {Stored HF} trip.
2001*
Create a boot file on a non-volatile media card based on the present drive parameters including all
Menu 20 parameters
4yyy* NV media card: Transfer the drive parameters to parameter file xxx
5yyy* NV media card: Transfer the onboard user program to onboard user program file xxx
6yyy*
NV media card: Load the drive parameters from parameter file xxx or the onboard user program from
onboard user program file xxx
7yyy* NV media card: Erase file xxx
8yyy* NV Media card: Compare the data in the drive with file xxx
9555* NV media card: Clear the warning suppression flag
9666* NV media card: Clear the warning suppression flag
9777* NV media card: Clear the read-only flag
9888* NV media card: Set the read-only flag
9999* NV media card: Erase and format the NV media card
110S0
Transfer electronic nameplate motor object parameters from the drive to an encoder connected to
the drive or an option module.
110S1
Transfer electronic nameplate motor objects parameters from an encoder connected to the drive or
option module to the drive parameters.
110S2 As 110S0, but for performance object 1
110S3 As 110S1, but for performance object 1
110S4 As 110S0, but for performance object 2
110S5 As 110S1, but for performance object 2
110S6
Transfer electronic nameplate motor object parameters from the drive to an encoder connected to
the drive or an option module in the Unidrive SP format.
12000**
Only display parameters that are different from their default value. This action does not require a
drive reset.
12001**
Only display parameters that are used to set-up destinations (i.e. DE format bit is 1). This action does
not require a drive reset.
15xxx*
Transfer the user program in an option module installed in slot 1 to a non-volatile media card file xxx
16xxx*
Transfer the user program in an option module installed in slot 2 to a non-volatile media card file xxx
17xxx*
Transfer the user program in an option module installed in slot 3 to a non-volatile media card file xxx
18xxx*
Transfer the user program from file xxx in a non-volatile media card to an option module installed in slot 1.
19xxx*
Transfer the user program from file xxx in a non-volatile media card to an option module installed in slot 2.
20xxx*
Transfer the user program from file xxx in a non-volatile media card to an option module installed in slot 3.
21xxx*
Transfer the user program in an option module installed in slot 4 to a non-volatile media card file xxx.
22xxx*
Transfer the user program from file xxx in a non-volatile media card to an option module installed in slot 4.
Unidrive M702_HS72 Control GSG Iss2.book Page 28 Friday, December 12, 2014 1:05 PM
