7.5.17 Object Model
The Object Model has the following object classes present.
Table 7.21 Supported Objects
7.5.18 Identity object
Class: 0x01 (1
10
)
The identity object provides identification of and general information about the device.
Object
Class
Class Code
Number of
Instances
Effect
Decimal Hex (0x)
Identity 1 01 1 Provides device specific information.
Assembly 4 04 16
Defines the I/O data format (parameter
mapping).
Motor Data 40 28 2 Defines the motor data.
Control
Supervisor
41 29 1
Provides drive control and monitoring
information.
AC/DC
Drive
42 2A 1
Provides drive configuration and
running state information.
CT Group 100 64
<No. of
menus>
Provides access to drive parameters.
CT This Slot 101 65
<No. of
menus>
Provides access to the local option
module parameters.
CT Slot 1 102 66
<No. of
menus>
Provides access to the option module
parameters in slot 1.
CT Slot 2 103 67
<No. of
menus>
Provides access to the option module
parameters in slot 2.
CT Slot 3 104 68
<No. of
menus>
Provides access to the option module
parameters in slot 3.
CT Slot 4 105 69
<No. of
menus>
Provides access to the onboard
Ethernet interface parameters.
Table 7.22 Identity object
Attribute Access Name Data Type
1 Get VendorID UINT
2 Get DeviceType UINT
3 Get ProductCode UINT
4 Get Revision USINT
6 Get SerialNumber UDINT
7 Get ProductName SHORT_STRING
