Emerson Unidrive M400 Quick Start Quide

18 Unidrive M400 Quick Start Guide
Issue Number: 5
Figure 4-7 Pr 00.005 = Keypad Ref (50 and 60 Hz)
Figure 4-8 Pr 00.005 = Electronic Pot (50 and 60 Hz)
1
2
3
4
0V
Voltage speed reference
input (AI 1+)
AI 1-
5
6
7
8
0V
Analog output 1
(motor frequency)
+ 10 V output
Analog output 2
(motor active current)
9
10
11
Digital output
(zero frequency)
Unassigned
12
13
14
15
16
17
Analog input 1/
input 2 select
Run forward
+ 24 V output
Jog Forward
Unassigned
+ 24 V output
10k
Run reverse
Voltage speed reference
input (AI 2)
10k
1
2
3
4
0V
Voltage speed reference
input (AI 1+)
AI 1-
5
6
7
8
0V
Analog output 1
(motor frequency)
+ 10 V output
Analog output 2
(motor active current)
9
10
11
Digital output
(zero frequency)
Unassigned
12
13
14
15
16
17
UP
Run forward
+ 24 V output
Jog Forward
Unassigned
+ 24 V output
10k
Run reverse
DOWN
When Pr 00.005 is set to Electronic Pot, the
following parameters may need to be
adjusted:
•Pr 09.023: Motorized pot up/down rate
(s/100 %)
•Pr 09.022: Motorized pot bipolar select
(0 = unipolar, 1 = bipolar)
•Pr 09.021: Motorized pot mode: 0 = zero
at power-up, 1 = last value at power-up,
2 = zero at power-up and only change
when drive is running,
3 = last value at power-up and only
change when drive is running,
4 = zero at power-up and drive disabled,
only change when drive is running.
