The ON/OFF Function Parameters • 13
Hd2 Second weekly holiday (Sun to
not used)
Set the second day of the week that follows the holiday times.
NOTE: Hd, Hd2 can be set also as “not used” value.
TO SET ENERGY SAVING TIMES (ONLY FOR MODELS WITH RTC)
iLE Energy Saving cycle start dur-
ing workdays
(0 to 23 hr 50 min)
During the Energy Saving cycle, the setpoint is increased by the value in HES so that
the operation setpoint is SEt + HES.
dLE Energy Saving cycle length dur-
ing workdays
(0 to 24 hr 00 min)
Sets the duration of the Energy Saving cycle on workdays.
iSE Energy Saving cycle start on
holidays. (0 to 23 hr 50 min)
dSE Energy Saving cycle length on
holidays (0 to 24 hr 00 min)
TO SET DEFROST TIMES (ONLY FOR MODELS WITH RTC)
Ld1
to
Ld6
Workday defrost start (0 to 23
hr 50 min)
These parameters set the beginning of the 6 programmable defrost cycles during work-
days. Ex. When Ld2 = 12.4 the second defrost starts at 12.40 during workdays.
Sd1 to
Sd6
Holiday defrost start (0 to 23 hr
50 min)
These parameters set the beginning of the 6 programmable defrost cycles on holidays.
Ex. When Sd2 = 3.4 the second defrost starts at 3.40 on holidays.
NOTE :To disable a defrost cycle, set it to not used. Ex. If Ld6 = not used ; the sixth
defrost cycle is disabled
OTHER PARAMETERS
Adr Serial address (1 to 244) Identifies the device address when connected to a MODBUS compatible monitoring
system.
pbC Type of probe Allows to set the kind of probe used by the device:
Pt1 = Pt1000 probe
ntc = NTC probe
onF ON/OFF key enabling not used = disabled
oFF = enabled
ES = not set it
dP1 Thermostat probe display
dP2 Evaporator probe display
dP3 Third probe display - optional
dP4 Fourth probe display
rSE Real
setpoint Shows the setpoint used during the energy saving cycle or during the continuous cycle.
rEL Software release For internal use only
Ptb Parameter table code Read-only
Code Parameter Function
Table 7-1 - List of Parameters
