Page #32 background imageLoading...
Page #32 background image
32
C
D
E
F
Bedeutung
C
D
2.
[*F]
Tariff 2
C
D
3.
[*F]
Tariff 3
C
D
4.
[*F]
Tariff 4
31.
25
Instantaneous value current phase 1
51.
25
Instantaneous value current phase 2
71.
25
Instantaneous value current phase 3
32.
25
Instantaneous value voltage phase 1
52.
25
Instantaneous value voltage phase 2
72.
25
Instantaneous value voltage phase 3
1.
25
Instantaneous value active power total
3.
25
Instantaneous value reactive power total
C.
1.
0
Manufacturing number
C.
5.
Internal operational conditions
C.
7.
0
Number of voltage failures 3 phase
C.
7.
1
Number of voltage failures L1
C.
7.
2
Number of voltage failures L2
C.
7.
3
Number of voltage failures L3
C.
51.
1
[*F]
Pre-value voltage failures phase 1
C.
51.
2
[*F]
Pre-value voltage failures phase 2
C.
51.
3
[*F]
Pre-value voltage failures phase 3
C.
51.
5
Date/time of the last manipulation of the terminal cover (start)
C.
51.
5
[*F]
Pre-value terminal cover manipulation (start)
C.
51.
6
Date/time of the last manipulation of the terminal cover (end)
C.
51.
6
[*F]
Pre-value terminal cover manipulation (end)
C.
51.
7
Total number of the terminal cover manipulations
C.
52.
1
[*F]
Pre-value voltage return phase 1
C.
52.
2
[*F]
Pre-value voltage return phase 2
C.
52.
3
[*F]
Pre-value voltage return phase 3
C.
52.
5
Date/time of the last manipulation (start)
C.
52.
5
[*F]
Pre-value magnet manipulation (start)
C.
52.
6
Date/time of the last magnet manipulation (end)
C.
52.
6
[*F]
Pre-value magnet manipulation (end)
C.
52.
7
Total number of magnet manipulations
C.
86.
5
Radio status register
C.
90.
0
Check sum PAR
C.
90.
1
Check sum SET
C.
90.
2
Check sum ROM
F.
F
Error register
195
8
0
Reactive energy Q1, tan( ) energy register tariff 0
195
8
0
[*F]
Pre-value reactive energy Q1, tan( ) energy register tariff 0
196
10
Active energy + over consumption energy register tariff 0
196
10
[*F]
Pre-value active energy + over consumption energy register
Table 9: OBIS-codes
