Cassette Air Handler
46
37.00
49.26
47.78
24.73
3.38
REF
2.72
REF
5.12
1.97
14.01
REF.
2.04
8.90
1.41
3.65
44.68
32.44
.875Ø
Large Cabinet • Cassette 36 • 30,000 - 36,000 Btuh
CASSETTE DIMENSIONS
Note: All dimensions in inches.
Cassette 36
B
Control
Box
F
D
E
C
6.87
4.37
4.00
5.00
5.47
4.68
42.66
29.19
43.45
1.63
TYP
FEATURE QTY. SIZE
A
Optional
Discharge
Knockout
3 5¼” Ø
B
Fresh Air Inlet
Knockout
3 3 x 3”
C
Condensate
Discharge
1
½” Ø
D Suction 1
¾” Ø
E Liquid 1
⅜” Ø
F
Condensate
Pump Access
1
-
