Cassette Air Handler
50
CASSETTE SYSTEM MATCHES
SYSTEM OPTIONS WITH T4CA TOP DISCHARGE
Cassette
Qty
Condenser Btuh SEER SHR EER Ref.
CAH_12 4 T4CA9999 35,200 13.0 0.87 11.4
R22
CAH_12 4 T4CA2222 46,000 13.0 0.76 11.4 R22
CAH_12 4 T4CA9222 43,000 13.0 0.77 11.4 R22
CAH_12 4 T4CA9992 37,800 13.0 0.79 11.4 R22
CAH_12 4 T4CA9922 40,500 13.0 0.82 11.4 R22
SYSTEM OPTIONS WITH T3HA TOP DISCHARGE
Cassette Qty Condenser
Cooling
Btuh
Heating
Btuh
SEER SHR EER COP Ref
CAH_12 3 T3HA9920 29,800 25,800 13.0 0.78 11.7 3.1 R22
CAH_12 +
CAH_24
2+1 T3HA9980 36,400 29,000 13.0 0.77 12.2 3.1 R22
CAH_12 +
CAH_24
2+1 T3HA9940 42,500 35,800 13.0 0.72 11.9 3.1 R22
CAH_12 3 T3HA9220 31,800 27,800 13.0 0.76 11.6 3.1 R22
CAH_12 +
CAH_24
2+1 T3HA9280 38,500 31,000 13.0 0.75 12.1 3.1 R22
CAH_12 +
CAH_24
2+1 T3HA9240 44,500 37,800 13.0 0.71 11.8 3.1 R22
CAH_12 +
CAH_24
2+1 T3HA2280 40,500 33,200 13.0 0.75 12.0 3.1 R22
CAH_12 +
CAH_24
2+1 T3HA2240 46,500 40,000 13.0 0.71 11.8 3.1 R22
CAH-12 3 T3HA2220 34,000 30,000 13.0 0.75 11.6 3.1 R22
SYSTEM OPTIONS WITH T4HA TOP DISCHARGE
Cassette Qty Condenser
Cooling
Btuh
Heating
Btuh
SEER SHR EER COP Ref
CAH_12 4 T4HA9999 37,200 31,800 13.0 0.80 11.9 3.2 R22
CAH_12 4 T4HA9992 39,000 33,800 13.0 0.78 11.8 3.1 R22
CAH_12 4 T4HA9922 41,000 35,800 13.0 0.77 11.7 3.1 R22
CAH_12 4 T4HA9222 43,000 37,800 13.0 0.75 11.5 3.1 R22
CAH_12 4 T4HA2222 45,000 40,000 13.0 0.75 11.6 3.1 R22
NOTE: CAH_ refers to CAHA or CAHB
CAC_ refers to CACA or CACB
