EMKO ERM-3770 - Process Input Connection

3.5.1ProximityConnection
3.5ProcessInputConnection
16
10
12 11
12V
Max.30mA
Z
0V Z
Input
PROX.
PNP
PNP typeoperation
=
10
12 11
12V
Max.30mA
Z
0V Z
Input
PROX.
NPN
NPNtypeoperation
=
Sensor Supply Voltage is 12 V %35 maximum 30 mA.Z ±
i
3.5.2SwitchConnection
10 12 11
Input
Switch
0V Z
12V
Max.30mA
Z
=
10 12 11
Input
Switch
0V Z
12V
Max.30mA
Z
=
PNP typeoperation NPNtypeoperation
