EMKO ERM-3770 - Front View and Dimensions (Alarm Output)

2.1GeneralDescription
2.2FrontViewandDimensionsofERM-3770DigitalTachometerWith AlarmOutput
MountingClamp
FrontPanel
IP65protection
NEMA 4X
Panelsurface
(maximumthickness15mm/0.59inch)
8
Maximum15 0.59inchmm/
58.5mm/2.30inch4mm/0.16inch
35mm/1.38inch
77mm/3.03inch
DigitalTachometer
SET
ERM-3770
P
OP
SIG
SV
