1.2. General Specifications
1.Preface
ESM 3722 series Hatcher controllers are designed for controlling hatcher process. Device
can be used easily with PID or On-Off control form and manual start of egg tray rotator properties.
ESM-3722
Power Supply
Input
Output
Output
Output
2
Humidification
Egg Tray Rotator Output
Alarm
1.1 Environmental Ratings
230V ( %15)50/60HzV ±
Optional Supply
Voltage
- 30 V Z
115 V (±%15)50/60Hz
24 V (±%15)50/60Hz
24 V (±%15)50/60Hz
10
V
V
W
Standard
Output
Heating
Operating Temperature : -20 to 70 °C
Max. Operating Humidity : 90% Rh (non-condensing)
Altitude : Up to 2000 m.
Forbidden Conditions:
Corrosive atmosphere
Explosive atmosphere
Home applications (The unit is only for industrial applications)
Temperature Sensor
Input
Humidity Sensor Input
0/2..10V, 0/4..20mA or
ProNem Mini PMI-P
PTC, NTC, PT-100
0/2..10V,0/4..20mA or
ProNem Mini PMI-P
