3.2 Device Label and Connection Diagram
230VV CONNECTION DIAGRAM
PTC Temperature and 0/4 @20mA Humidity Sensor Input connection
ProNem Mini PMI-P Temperature and Humidity Sensor Input Connection
N
L
7
8
9
10
a
3x3A@ 250V V
5A @250VV
L
N
230 VV ± 15%
50/60Hz - 1.5VA
2
3
41
5
6 11 12
14A T Fuse
+
-
HEAT. ALARM
HUM.
HUM. ALARM/
HEAT
230 VV ± 15%
50/60Hz - 1.5VA
N
L
7
8
9
10
a
3x3A@ 250V V
5A @250VV
L
N
230 VV ± 15%
50/60Hz - 1.5VA
2
3
41
5
6 11 12
14A T Fuse
+
-
VCC GND SCL SDA
WHITE
YELLOW
BROWN
GREEN
ProNem Mini
PMI-P
BLACK
Shield
230 VV ± 15%
50/60Hz - 1.5VA
HEAT
ALARM
HUM.
HEAT
HUM. ALARM/
Note : (Black) pin must be connected to number 10 (GND) of the terminal block.Shield
