EMKO ESM Series - Dimensional Views; ESM-4420, ESM-4920, ESM-7720 Views

5
Maximum 15mm / 0.59 inch
84 mm / 3.31 inch
11.5 ± 1 mm /0.45 inch
ESM-7720
72mm / 2.83 inch
72mm / 2.83 inch
°C
°F
PO
AO2
PS
AS2
Temperature Controller
ASET
ESM-7720
P
PSET
AO1
AS1
ESM-4920
°C
°F
Temperature Controller ESM - 4920
PS
AS1
AS2
PO
AO1
AO2
P
PSET ASET
48mm/ 1.89 inch
96mm / 3.78 inch
84mm / 3.31 inch10.5 ± 1 mm /0.43 inch
Maksimum 15mm / 0.59 inch
ESM-4420
84 mm / 3.31 inch
Maximum 5mm / 0.2 inch
11 ± 1 mm /0.43 inch
ESM-4420
ASET
Temperature Controller
P
PSET
°C
°F
PO
AO2
PS
AS2
48 mm/ 1.89 inch
48 mm/ 1.89 inch
AO1
AS1
Dimension
