emmeti CTUP - Display Indications

English
- 38 -
Chronothermostat with Humidistat User Manual
■ display indications
14) "Day" Field
15) "Measured humidity" Field Note: the decimal point indicates the status of
humidistat relay (point ON = connected load,
point OFF = disconnected load)
16) "Environment temperature" Field
17) "Set program" Field
18) "Manual operation activation" Field
19) "Timer" Field
20) "Air conditioning activation" Field
21) "Heating activation" Field
22) "Clock" Field
23) "Phone dial"
Field (not used)
24) "Radiofrequency transmission" Field (not used)
25) "Unit of measurement" Field
26) "Off" Field
14
24 19
16
26
22
21
20
18
15
25
17
23
