EMP WP120 24V - Specifications; Dimensions and Hole Locations;Bolt Spacing

Specifications
© 2021 EMP Inc. 6
Specifications
Model 12V 24V
Performance
Operating Temperature Maximum:
203
°F (95 °C) 203 °F (95 °C)
Operating Temperature Minimum:
-40
°F (-40 °C) -40 °F (-40 °C)
Motor Speed Maximum: 5500 rpm 5500 rpm
Motor Speed Minimum: 1000 rpm 1000 rpm
Mechanical
Component Construction Cast Aluminum Cast Aluminum
Component Weight 6.2 lbs (2.8 kg) 6.2 lbs (2.8 kg)
Electrical
Input Voltage 9–16 V DC (14 V Nominal) 18–32 V DC (28 V Nominal)
Operating Current Draw Maximum 27.5 A 22 A
Thermal Protection Auto self-protect rpm rollback Auto self-protect rpm rollback
Dimensions and Hole Locations/Bolt Spacing
NOTE: 1 inch (25.4 mm) inside diameter hose for inlet and outlet connections.
