36167-1-0316Page 22
VENTING FIREPLACE - TOP
Position the Fireplace
Cut the Hole
See Figure 34 on page 21.
VENT CAP
9” (229mm) MINIMUM
TO SIDE WALL
Figure 35
MAXIMUM HORIZONTAL
RUN WITH 12” VERTICAL
RISE AND 90° ELBOW
MAXIMUM HORIZONTAL
RUN WITH MINIMUM
VERTICAL RISE AND
90° ELBOW
PIPE STRAPS
EVERY2’ (61cm)
8’ (244cm)
TO BOTTOM
OF UNIT
3’
(914mm)
20’ (6.1m)
(NOTE: STANDOFFS REMOVED FOR CLARITY)
Figure 36
