mode:
volume: controls the overall output
volume of the delay.
modulation: applies modulation to the delayed signal.
selects the sub-mode: a, b, or c.
See the Overview of Modes and Sub-modes section for a
detailed explanation of how the sub-modes work in each mode.
presets switch: cycles through the stored presets, performs additional
tasks in looper mode.
Controls at a Glance
9V -12V DC positive
tip 2.1mm jack. 300mA or greater
+
norm- normal, d time knob controls delay time (p 5)
tap- tap controls delay time (p 6)
auto- autoset (p 7)
rev- reverse delay (p 8)
rhy- rhythm (p 11)
tape- tape delay (p 12)
misc- miscelaneous modes (p 13)
loop- looper mode (p 14)
-the slow setting is a slower, more subtle modulation.
-the fast position is a faster, slightly deeper modulation.
bypass switch:
bypassed (true bypass).
INPUTOUTPUT
