EMS AIRFLOW ONE User Manual

10 11
5.2- Attaching and removing AIRFLOW
®
or PERIOFLOW
®
Handpiece
In order to ensure perfect electronic connection, the individual components must be dry.
Attaching the
AIRFLOW
®
or
PERIOFLOW
®
Handpiece
Connect the Handpiece to the hose.
Removing the
AIRFLOW
®
or
PERIOFLOW
®
Handpiece
Disconnect the Handpiece from the hose.
5.3- Attaching and removing PERIOFLOW Nozzles
Single-use PERIOFLOW Nozzle.
Cannot be reprocessed.
DO NOT use the PERIOFLOW Nozzle if the
package is damaged or opened.
Fully connect the PERIOFLOW Nozzle by
pushing on a hard surface.
Make sure the PERIOFLOW Nozzle is correctly
attached = fully inserted and right way
Remove the nozzle by using the PIEZON
®
Instrument check tool
Risk of injury: Always USE the PIEZON
®
Instrument check tool.
DO NOT remove by hand.
DEVICE USE
I- INTERFACES
4
3
1
2
5
6
BOOST
USE FORCE
NORMAL
PRESS GENTLY
1 ON/OFF-mode Standby
ON: the device goes into operating mode.
OFF: the device reverts back to standby.
(After 1 hour of inactivity, the unit switches to standby)
2
Powder chamber
pressurization /
depressurization
Powder chamber is pressurized or depressurized.
A white light illuminating the powder chamber will turn on when pressurized.
During chamber depressurization, the AIRFLOW
®
cord will automatically purge and the white light will
turn off at the end of the process.
Entering Standby mode: The powder chamber depressurizes automatically.
Powder chamber depressurization may take up to 10 seconds to complete.
During this time, it is recommended that you leave the AIRFLOW
®
Handpiece in its holder with the nozzle
facing down to avoid spraying the purged air and residual powder upwards.
3 Power setting
Place your finger in the groove below the numbers to adjust AIRFLOW
®
air pressure:
• 0 (water only, blue indicator)
• 10 (Maximum)
Memorization of the preselected settings.
4 AIRFLOW
®
water
Sets the AIRFLOW
®
water flow rate.
5 Pedal (normal)
Press the edge of the pedal for normal operation.
The pedal is deactivated when handpiece cord is placed in its holder.
6
Pedal BOOST
(Only on the wireless
pedal)
Pressing hard on the center of the wireless pedal activates power boost.
For easy boost activation: leave the foot on the pedal and put the heel up.
Scan
for
support
IV- WATER SUPPLY AND WATER BOTTLE
What water should I include in my WATER bottle?
EMS recommends the use of:
Filtered drinking water
Good quality tap water
Distilled water
The temperature must be between 10°C and 30°C. All other liquids can damage your device and void your warranty.
How to fill your water bottles?
Fill both bottles each morning with filtered water or good quality tap water (keep one as a back up to ensure uninterrupted
treatment flow).
To remove and place the bottle, use a straight up and down movement (do not shake the bottle to avoid damages).
At the end of every day: empty your bottles and allow to dry.
Once a week: wash your bottles with warm soapy water, rinse thoroughly and allow to dry.
It is also recommended to use a bottle cleaning agent weekly.
Without Bottle:
AIRFLOW
®
uses external water supply.
With WATER Bottle connected:
AIRFLOW
®
uses bottle liquid supply.
The CLIP+CLEAN shall be previously cleaned and
sterilized before use.
Non-cleaned and sterilized CLIP+CLEAN may contaminate
the device.
Place the CLIP+CLEAN into the device’s bottle receptacle
for dust protection.
Connect the WATER bottle
Only use the WATER bottle EG-121 (transparent) for water.
Water supply when on a STATION+
It's important to note the following configurations with the WATER Bottle when your AIRFLOW
®
ONE is on a STATION+.
AIRFLOW
®
TREATMENT – NO WATER AIRFLOW
®
TREATMENT – WATER bottle B
AIRFLOW
®
TREATMENT – WATER bottle A AIRFLOW
®
TREATMENT – WATER bottle A
DO NOT sterilize the WATER bottle and its nozzle cap by steaming or dry thermal reprocessing.
V- AIRFLOW
®
AND PERIOFLOW
®
HANDPIECES
5.1- Before rst use
EMS AIRFLOW
®
and PERIOFLOW
®
Handpieces are sterilizable and need to be cleaned and sterilized before use. Non
reprocessed Handpieces may cause bacterial or viral infections.
Follow the recommendations of the "Reprocessing Instructions" (FB-358/NA) manual delivered with your product regarding
procedure for cleaning, disinfecting and sterilizing the components, and the present-day regulations on reprocessing in effect
in your country.
In case the AIRFLOW
®
or PERIOFLOW
®
Handpieces get clogged, refer to the “Maintenance & Troubleshooting” section for
instruction.
