ASSEMBLY INSTRUCTIONS EC18014 / EC18015
5
Rail End Cap (8)
4 installed; 4 loose
Joiner Clip (4)
Top Rail (2)
1½" x 1½" x 63¼"
Thin Slat (10)
¼" x 1¼" x 62"
Wide Slat (12)
⁄" x 2⁄" x 62"
Middle Post (2)
⁄" x 1" x 52 ½"
STEP 2: LAY OUT MATERIALS
A B
E
HC
I
D
J
¾" Self-Drilling
Steel Screws (32)
Square Slat (10)
⁄" x ⁄" x 62"
End Post (4)
⁄" x 1 ½" x 59"
Bottom Rail (2)
1½" x 1½" x 63¼"
G
F
NOTE: Top rail has large cut
holes on one side only
