ENCLO Premium - Step 2: Assemble Full Panel

www.encloscreens.com
5
ASSEMBLY INSTRUCTIONS ZP19014
STEP 2: ASSEMBLE FULL PANEL
b Identify the Left Post (B) and Center Post (C) as
illustrated. With a helper, slide a Board Wall (E) down
the grooves until the board wall hits the factory
installed screws (roughly 2" from the bottom).
b Fasten each post to the board walls using (2) 2½"
Self-Drilling Stainless Steel Screws (G).
STEP 2.1
STEP 2.2
Top View
Left Post will have
two pre-drilled holes
at one corner and one
factory installed screw
at the bottom.
Center Post will have
four pre-drilled holes
at one corner and one
factory installed screw
at the bottom.
Note: Factory installed screws
should be facing inward.
Note: Make sure the board
is tight to the back of the
groove in the post.
B
C
E
Top View Top View
Note: Make sure you install the 2½"
self-drilling stainless steel screws straight
through and not at an angle
G
