ASSEMBLY INSTRUCTIONSZP19014
STEP 2.3
STEP 3.1
STEP 3: INSTALL SCREEN INTO THE GROUND
F
D
b Repeat steps 2.1 through 2.3 with the center post
and Right Post (D) for the second panel as shown.
b Insert the Ground Stakes (F) with the blade
down into the grooves of the left and right
posts as illustrated
b With a helper, move
the entire screen to
the intended position,
Then use a claw
hammer to loosen
rst 6 to 8 inches
of hard packed soil
as illustrated. Add
water to loosen soil as
necessary.
b Add three more board walls, and fasten the
top board wall into the left and center posts
as illustrated.
STEP 2.4
STEP 3.2
