Rear Panel
The figure below shows the rear panel of the Broadband Router.
Rear Panel
WAN
In the four port broadband router, there is an RJ-45 10/100Mbps Auto-
MDIX port for the WAN that will fit the xDSL/Cable modem’s
specification need.
LAN (1-4)
Four RJ-45 10/100Mbps Auto-MDIX ports for connecting to either
10Mbps or 100Mbps Ethernet connections.
RESET
Use a pin-shape item to push to reset this device to factory default settings.
It will be useful too when the manager forgot the password to login, but
the setting will be back to default setting.
