BELT-DRIVE WALK BEHIND MOWER
21
PRE-START
Fill fuel tank on level ground. For best results
use only clean, fresh regular grade unleaded
gasoline with an octane rating of 87 or higher.
IMPORTANT: Never use methanol, gasoline
containing methanol, gasohol containing
more than 10% ethanol, premium gasoline,
or white gas because the fuel system could
be damaged.
Do Not add oil to gasoline
Do Not over fill fuel tank. Fill the fuel tank to
the bottom of the filler neck. The empty space
in the tank allows gasoline to expand.
Overfilling may result in fuel leakage or damage
to the engine or emission system.
Make sure you understand the controls, their
locations, their functions, and their safety
requirements.
Refer to the Maintenance section and perform
all the necessary inspection and maintenance
steps.
OPERATING
INSTRUCTIONS
STARTING THE ENGINE
1. Move the transmission selector lever to the
neutral position.
2. Move both steering levers to the park brake
position and engage the brake locks.
3. Push in (down) on the PTO switch to the
“disengage” position.
4. Place the throttle midway between the
“SLOW” and “FAST” positions.
5. On a cold engine, pull the choke lever up
into the “ON” position.
6. On a warm engine, leave the choke in the
“OFF” position.
7. Turn ignition switch to the “ON” position.
8. Give the recoil starter a few quick pulls to
start the engine.
9. If the choke is in the “ON” position,
gradually return choke to the “OFF”
position as the engine warms up.
BLADE ENGAGEMENT
DANGER
The rotating blades under the mower deck
are dangerous. Blade contact can cause
serious injury or kill you.
Do Not put hands or feet under the mower
or mower deck when the blades are
engaged.
DANGER
An uncovered discharge opening will allow
objects to be thrown in an operator’s or
bystander’s direction. Also, contact with
the blade could occur. Thrown objects or
