BELT-DRIVE WALK BEHIND MOWER
31
NEUTRAL ADJUSTMENT
This adjustment may be necessary if certain
components have been replaced or reinstalled
1. Loosen the two bolts holding the shift lever to
the transmission lever and adjust so that the top
of it just touches the range indicator panel.
2. Loosen the two bolts holding the range indicator
panel in place, this will allow the panel to be
adjusted from side to side.
3. Move the panel as far to the left as possible.
4. Ensure that the transmission is in the Neutral
position, this will be one position to the right of
the full left position which is Reverse.
5. Gently slide the panel to the right until it just
makes contact with the shift lever.
RH DECK SPINDLE DRIVE BELT TENSION
This adjustment pertains to only those decks that
have 3 spindles.
Adjust tension rod to obtain 1/2" belt deflection
midway between right hand and center spindle
pulleys.
