🠚 four blinks assign the
TAP
footswitch to se;lect the
ROUTING
type
as if you press the
ROUTING BUTTON
(15) with a foot.
🠚
NOTE:
only one from four options can be assigned to
TAP
footswitch at a time
(either tap, either delay looper or selected reverb action). You may access all those
functions simultaneously via MIDI (see MIDI implementation chart at the end of the
manual).
BYPASS FOOTSWITCH MODES
There are three bypass options that can be selected by pressing and holding
SHIFT
+ BYPASS
for more than 4 seconds. The number of
SHIFT
button blinks shows the
selected
BYPASS
type:
🠚 one blink (by default):
TRUE BYPASS
means that the stereo relays are
physically connecting audio input jacks to the effects or detaching them from the
effects rerouting to the output jacks directly without any buffers. You may hear
clicks in the pedal inside during relay bypass switching. When the pedal is
unpowered, its bypass is always
true
enabled – meaning it will pass the audio
signals from audio
IN L/R
to audio
OUT L/R
accordingly preserving your tone.
🠚 two blinks:
BUFFERED BYPASS
means that the relays are always on and
we enable/disable effects chain in the DSP code setting the MIX control to CCW.
This type of bypass might be useful if you need a buffered audio input to preserve a
tone or volume amplitude.
🠚 three blinks :
TRAILS BYPASS
means a variation of buffered bypass,
however it keeps the whole effect chain active while the original signal is bypassed.
This type of bypass is useful if you wish to for example have a controlled long
reverb tails or delay still recirculating while the original signal passes clean.
RESET
In case you have tweaked everything so hard you have distorted signal main
outputs, a reset adjusts all advanced / secondary parameters to their default values,
so you may start tweaking from the beginning.
SOFT RESET
: press all four buttons (13) (15) (19) (23) simultaneously and hold them
for more than 3 seconds. Release them once all the LEDs are on and the pedal will
reset the current preset to its default values. Current preset is not saved – you have
to do that manually, otherwise the previously saved preset will be restored from that
slot on the next power up (see
PRESETS LOAD / SAVE
section below)
