SINGLE PRESET contains all knob values, routing, filter and reverb types,
modulation assignments and expression pedal settings. Those settings must be
manually saved via long hold PRESET footswitch (24) in one of the nine slots (25)
and are individual per each preset (see PRESETS LOAD / SAVE above).
🠚 IMPORTANT: presets are not autosaved! If a preset is not manually saved after
being edited (see PRESETS LOAD / SAVE section above), the previously saved
preset will be loaded on the next power up from the last selected 1-9 preset slot.
SOFT RESET (see RESET section above) clears currently selected preset to default
values while HARD RESET clears all 9 presets and global settings to default values.
If a soft reset is performed on a specific preset, then after powering the unit off and
on the preset will be reloaded (soft reset does not permanently delete preset data).
PRESET DUMP contains information about all 9 presets above and doesn’t include
any of the pedal’s settings below (so you can import presets of your friends and
they will not change your settings).
MOMENTARY SETTINGS contain states like Bypass enable, last preset selected
etc. Those are saved every 2 seconds once we change them. That means if you
selected the third preset on the pedal, enabled bypass and in 2 seconds turned the
pedal off, it will remain bypassed on the third preset recalled on the next power up.
GLOBAL SETTINGS contain settings about MIDI Thru enable, knobs CC values
sent to MIDI OUT, MIDI OUT enable, MIDI Clock out enable, Program change
Receive (RX) or Transfer (TX) enable, MIDI channel selected, Bypass type, internal or
external MIDI sync over LFO and Delay clock. These settings are global for all 9
presets and are also auto-saved after a slightly longer time period than momentary
settings.
Page 21 of 27
