disables the whole effects chain. When the effects chain is enabled, the
pink
LED
near that footswitch is ON. When the effect chain is bypassed, the LED
is off and also all the remaining LEDs except the preset selection LEDs are
dimmed. Additionally is used to confirm the load of the newly selected preset
with
PRESET
(24) footswitch.
21. SPEED
/MIDI CLOCK*
KNOB with LED:
controls the frequency
time (speed) of internal
LOW FREQUENCY OSCILLATOR
or
LFO
from
0.0333
Hz
(30 seconds per cycle) at CCW to
15 Hz
(0.0666 seconds per cycle) at CW
as a primary parameter. LED flashes in
red
LED according to internal LFO
clock. Secondary
/MIDI CLOCK*
function (pressing or holding
SHIFT
while
turning this knob from noon CW) enables the LFO SYNCHRONIZATION to an
external MIDI clock received at
MIDI IN
connector (5). In the external clock
mode this knob acts as a divider / multiplier for the clock with the divisors
similar to values around the
TIME/DIV
knob (9) and LED flashes
blue
according to the external MIDI clock speed.
22. LFO SHAPE
/MIDI CHANNEL*
KNOB with LED:
gradually
selects the LFO shape from the list below (the amount shown with the
brightness of the
red
LED). Secondary
/MIDI CH*
function (pressing or
holding
SHIFT
while turning this knob in 16 sectors from CCW to CW)
changes the MIDI channel from 1st to 16th that the pedal accepts and sends
the MIDI data on.
23. MODULATION
/EXPRESSION*
BUTTON with LED:
used to
assign LFO (22) and expression pedal (4). While holding this button (it will
light up) tweak any of the knobs. The amount by which you tweak this knob
from center position to the sides while holding the
MODULATION
button sets
the depth of the selected LFO (22), which will be applied to the assigned
parameter. Secondary combination of
SHIFT
+
MODULATION
will set the
expression pedal (4) morphing (see 4.
EXPRESSION PEDAL ASSIGNMENT
below for assigning procedure). Same as
SHIFT
(19),
MODULATION
button
has an additional latched action, so you may press it once to leave enabled
and adjust other parameters while operating with one hand only. After you
press and hold
MODULATION
, add some parameters modulations and
release the button - it turns that button action off.
24. PRESET
/HOLD TO SAVE
FOOTSWITCH:
selects one of 9 presets
(25). Once you select the preset, its LED starts to blink. To load that preset
you have to confirm it with the BYPASS footswitch (20). Loading the presets
will not alter current bypass effect state on or off.
To save the preset you have to hold the
PRESET
footswitch for longer than 3
seconds. One of the 9 slots will start to blink and you may choose the new
slot to save by pressing the
PRESET
footswitch a few times. To confirm the
preset save in the selected slot press and hold
PRESET
(20) footswitch for
longer than 3 seconds.
