Description of the device
6 Description of the device
6.1 Views
The following section provides an overview of the designation and location
of the most important components of your generator. It is important to en-
sure that you are familiar with these in order to further understand the de-
scribed functions and operating steps and to be able to perform these
safely. Severe or deadly personal injuries can result and/or damage to the
generator as well the attached power consuming equipment if these in-
structions are ignored.
In order to be in a position to clearly re-find named operating controls and com-
ponents in the following descriptions and instructions, the individual views of the
generator are designated throughout in a way which can be taken from the fol-
lowing figure.
Fig. 6-1 Views of the generator
Start side Exhaust gas side
Maintenance side Control side
