26
Description of the device
6.4 Control panel components
Fig. 6-4 Components on the control panel
Oil monitoring warning indicator Overload alarm
Indicator light ECOtronic On / Off
Battery recharging connection Connection for Potential equalisation de-
vice
230V / 16A / 1~ Schuko socket Multifunction switch
