40
Maintenance
Fig. 9-1 Checking and changing engine oil
Checking the oil
level
1. Loosen the three screws in the cover on the maintenance side and then re-
move it.
2. Loosen the yellow screw plug and remove it from the filling opening. AT-
TENTION! The screw is wetted with oil.
3. The attached oil dipstick shows the oil level in the engine.
The oil level has been checked.
