Liquisys M CPM223/253 Accessories
Endress+Hauser 103
10.3 Mounting accessories
CYY101 weather protection cover for field devices, absolutely essential if operating the unit
outdoors
• Material: stainless steel 1.4031 (AISI 304)
• Order No. CYY101-A
a0019166
Fig. 49: Weather protection cover for field devices
CYY102 universal post
• Square pipe for mounting transmitters
• Material: stainless steel 1.4301 (AISI 304)
• Order No. CYY102-A
a0005742
Fig. 50: Universal post
320 (12.6)
270 (10.6)
300 (11.8)
mm (inch)
1495 / 58.86
60x60/
2.36 x 2.36
120 /
4.72
150 /
5.91
mm/inch
