Endress+Hauser VU113 - Technical Data

VU113 Graphical display with keys and Bluetooth VU112 Graphical display with keys Operation options
Endress+Hauser 11
4.2 Access via Bluetooth® wireless technology
Bluetooth is optional, and is not an integral feature of the display (see the product
structure for the specific device).
1
2
A0041912
 1 Remote operation via Bluetooth® wireless technology
1 Smartphone or tablet with SmartBlue (app)
2 Display with optional Bluetooth function
4.2.1 Preparation
The serial number of the device serves as the initial password when the connection is
established for the first time. The serial number can be found on the nameplate of the device.
3
2
1
Ser. no.:
A0039215
1 Serial number on the nameplate of the device (sample illustration)
2 Serial number on the nameplate of the display (on rear) with information on Bluetooth certificates
3 Information on Bluetooth for VU113
4.3 Technical data
• Maximum free-field range 50 m (165 ft) for Bluetooth option
• Operation radius with intervisibility 10 m (33 ft) around the device for Bluetooth option
• Supply voltage: 3.2 V
DC
with max. 3.4 V
DC
and min. 3.1 V
DC
• Power consumption: max. 17 mW
• Current consumption: 5 mA
• Pollution degree: 2
