6.2 Operating elements
• Minus key
• In menu, submenu
Moves the bar up in a picklist
• In text and numeric editor
In the input mask, moves the bar to the left (backwards)
•
Plus key
• In menu, submenu
Moves the bar down in a picklist
• In text and numeric editor
In the input mask, moves the selection bar to the right (forwards)
•
Enter key
• Unlocking the display
Long key press (>2 s)
Unlock by selecting "Keylock Off" with +/- and pressing Enter to confirm
• On measured value display
Pressing the key briefly opens the operating menu
Pressing the key for 2 s opens the context menu (guide and keylock).
• In menu, submenu
Pressing the key briefly opens the selected menu, submenu or parameter
Pressing the key for 2 s on a parameter opens the help text for the parameter function, if
available.
• In text and numeric editor
Pressing the key briefly opens the selected group, performs the selected action
Pressing the key for 2 s on a parameter confirms the editable parameter value.
•
+
Escape key combination (press keys simultaneously)
• In menu, submenu
Pressing the key briefly exits the current menu level and takes you to the next higher
level; if help text is open, closes the help text for the parameter
Pressing the key for 2 s returns you to the measured value display ("home position").
• In text and numeric editor
Closes the text or numeric editor without applying changes
